Product Description: 100% solid copper conductor: 0.51mm, Colour-coded PE insulation, PE jacket Operation temperature: -10°C to 60°C, 24 AWG UTP (Unshielded Twisted Pair). Pair Identification: Pair 1 - Blue with White/Blue stripe, Pair 2 - Orange with White/Orange stripe, Pair 3 - Green with White/Green stripe, Pair 4 - Brown with White/Brown stripe. Specification: • Characteristic Impedance: 100ohms +/-15%, • Capacitance: 14pf/ft nominal, • DC resistance/Unbalance: 28.6ohms/1000'Max/5% Max, • Dielectric Breakdown: 2500 Volts DC Conductor to Conductor, • Nom. Velocity of Propagation: FEP=76%, • Maximum Skew: 25ns@100 meters. Product Features: • 100% Solid Copper Cable • £££ Value for money compared to cheaper CCA (Copper Clad Aluminium) /CCS (Copper Clad Steel) versions • Moulded RJ45 plugs, ready for plug and play. • Allows extensions to external rooms from current network Compliance: TIA/EIA 568b St...
